15 inch industrial chassis LCD touch monitor with VGA,DVI,HDMI input for koisk,gaming,industrial control
ITD Industrial chassis LCD Monitors are designed for those industrial and process control environments that require a stand-alone wall mounted display that does not need a complete seal from oil, dust, and other contaminants. These cost-effective LCD monitors support fast and slow-scan horizontal frequencies and are available with optional resistive, IR, SAW or capacitive touch screens.
BENEFITES
-Compliant with major safety regulations
-Perfect for kiosk, cabinets, equipment and instrument drop-in designs
-Superior viewing angles, contrast ratio and brightness
-Robust CNC milled open frame enclosure
- Chassis Mounting, VESA Mounting, Rear Mounting
-Unique design accounts for heat ventilation
-Durable Touchscreen options
-DVI, Composite and BNC video input options
| Chassis LCD Monitor |
| Model Name | ITD15CMN1M1 |
| IP Rating | N/A |
| LCD Panel |
| Screen Diagonal (Inch) | 15” |
| Display Active Screen Size (mm) | 304.13(H)×228.1(V) |
| Aspect Ratio | 4:3 |
| Physical Resolution | 1024×768 |
| Maximum Resolution Supported | 1980×1080 |
| Colors | 262K |
| Brightness (cd/m²) | 250 |
| Contrast Ratio | 700:1 |
| View Angels | 80/80/60/80 |
| Backlight/Backlight Lifetime | LED Backlight with 50000Hours’Lifetime |
| Touch Panel |
| Touch Options | Resistive, IR, PCAP, SAW |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
| Input / Output |
| Video Input | 1 × VGA |
| 1 × DVI-I |
| 1 × HDMI |
| Audio | 1 × PC-Audio |
| Touch Connector | 1 × USB |
| Power Connector | 1 × DC2.0 |
| Operation |
| Operating Temperature Range | -10~60°C (-20~70°C Optional) |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
| Power |
| Power Indicator | Green LED |
| Power Input | DC 12V |
| Power Consumption | 20W |
| Order Information |
| 15”Chassis LCD Monitor with Resistive Touch | ITD15CMT101 |
| 15”Chassis LCD Monitor with IR Touch | ITD15CMT201 |
| 15”Chassis LCD Monitor with SAW Touch | ITD15CMT301 |
| 15”Chassis LCD Monitor with PCAP Touch | ITD15CMT501 |
| 15”Chassis LCD Monitor with Tempered Glass | ITD15CMG101 |
APPLICATION
CERTIFICATE
OUR FACTORY
Product Tags:
|
|
